    Truck Offroad Metal Air Ride Pneumatic Dc12v Car Air Compressor For Air Tool Brake With Tank Suspension Pump

    Ask Lasest Price
    Brand Name : YURUI
    Model Number : YF6355R
    Certification : CE&ROHS
    Price : Consultation
    Payment Terms : T/T, L/C
    Supply Ability : 4000pcs 30 days
    Delivery Time : 30 days after receiving 30% deposit
    • Product Details
    • Company Profile

    Truck Offroad Metal Air Ride Pneumatic Dc12v Car Air Compressor For Air Tool Brake With Tank Suspension Pump

    YURUI 6355R 150psi 12V and 24V Pewter Stainless Lead Hose Air Suspension Compressor


    Description
    YF6355R is an installation type air suspension pump, which specifically applies to the professional equipment where needs fast-speed and extensive air, such as tire inflation, agriculture seeder, armaria, extracting oil and even in aircraft manufacturing corporation. Always integrated into on-board air system.
    Commonly used must with air tanks in car tuning like off-road cars.The compressor is consist with an on-off pressure button. It automatically turns on and off when the pressure reaches the certain level. The part, air filter can be used in a remote situation when the environment changes. The compressor is furnished with a thermal overload protector which will turn off the unit if overheated.
    Used with
    Air tanks in different sizes
    Pneumatic system
    Air horns
    Our Advantages
    1 . One year warranty
    2 . Competitive price than other manufactures
    3 . Portable to carry with
    4 . Fast inflation and low noise
    5 . Can be pumped more than 20 , 000 times
    6 . Anti-dust and explosion-proof
    7 . Water resistant : IP 67, working in the water for 2 hours



    SPECIFICATION
    1. 40CFM 12V 150PSI
    1. 50CFM 24V 150PSI
    12 Volt
    Duty Cycle: 33% @ 100 PSI
    Max. Working Pressure: 150 PSI
    12V Max. Amp Draw: 22 Amps
    24V Max. Amp Draw: 12 Amps
    3/8"NPT Inlet port
    Net Weight: 6.6lbs
    8"Lx4"Wx6.45"H
    PERFORMANCE DATA 12V

    PSI04090150
    AMPS11161818
    CFM1.41.030.90.74
    LPM40322621
    BAR03610


    RECOMMENDED TANK
    TANK FILL DATA 12V
    2.0 Gallon Tank
    0 to 150 psi 3min 55 sec
    120 to 150 psi 50 sec
    PERFORMANCE DATA 24V

    PSI04090150
    AMPS691011
    CFM1.51.271.020.77
    LPM42362922
    BAR03610


    RECOMMENDED TANK
    TANK FILL DATA 24V
    2.0 Gallon Tank
    0 to 150 psi 3 min 15 sec
    120 to 150 psi 46 sec


    ♦ DUTY CYCLE REFERENCE CHART

    Duty Cycle: 100PSI @ 72FMax. Run Time / Min. Rest Time
    Duty cycle refers to the amount of time compressor can be operated in a given time period at 100PSI and a standard ambient temperature of 72F. Duty cycle is commonly expressed in percentage format as: Compressor on time / (on time + off time)= Duty Cycle%
    9% Duty Cycle3 Min. On / 30 Min. Off
    10% Duty Cycle3 Min. On / 30 Min. Off
    15% Duty Cycle6 Min. On / 30 Min. Off
    20% Duty Cycle8 Min. On / 30 Min. Off
    25% Duty Cycle10 Min. On / 30 Min. Off
    30% Duty Cycle13 Min. On / 30 Min. Off
    33% Duty Cycle15 Min. On / 30 Min. Off
    40% Duty Cycle20 Min. On / 30 Min. Off
    100% Duty CycleContinous Duty @ 100PSI @ 72F
